Right-Angle Planetary Gearheads
Right-angle gearheads for compact machine layouts where axial space is limited but precision and torque are still required.
Target Buyer:For integrators balancing torque, footprint, and cable routing constraints.
Capability Highlights
- Space-saving 90-degree architecture
- Supports high-torque transmission in constrained envelopes
- Flexible output shaft and mounting options
Typical Applications
- Conveyor transfer and side-drive modules
- AGV sub-assemblies and mobile automation axes
- Packaging equipment with tight installation spaces
Engineering Focus
- Input-output orientation and cable management space
- Output bearing load and overhung load limits
- Noise and temperature validation at rated duty
Key Evaluation Matrix
| Metric | Typical Range | Why It Matters |
|---|---|---|
| Output Torque Range | 20-1200 Nm | Defines the achievable payload and acceleration capability of the axis. |
| Efficiency | 88-95% | Efficiency impacts thermal behavior and long-cycle energy use. |
Risk Controls
- Ignoring overhung load at output: Confirm bearing load limits and add support structure when necessary.
- Thermal accumulation in enclosed cabinet: Model heat dissipation and verify temperature at peak duty operation.
Product Selection Worksheet
Use this worksheet in your internal review to convert assumptions into explicit RFQ inputs before supplier quotation.
| Decision Gate | Buyer Question | Evidence to Request | Release Condition |
|---|---|---|---|
| Output Torque Range | Defines the achievable payload and acceleration capability of the axis. | Available installation envelope and mounting orientation | Risk control agreed: Confirm bearing load limits and add support structure when necessary. |
| Efficiency | Efficiency impacts thermal behavior and long-cycle energy use. | Output shaft loading condition (radial/axial/overhung) | Risk control agreed: Model heat dissipation and verify temperature at peak duty operation. |
Minimum first-email payload: motor model, load profile, target ratio range, acceptance threshold, and sample quantity timeline.
Sample-to-MP Handoff Checklist
- Freeze drawing and requirement baseline before sample release.
- Record pass/fail evidence for the same metrics used in quotation.
- Log all engineering changes with revision ownership on both sides.
- Approve mass-production release only after acceptance evidence and delivery milestones are aligned.
Product Gallery
Buyer FAQ
Can right-angle units maintain precision for indexing tasks?
Yes, with proper backlash class selection and load-side stiffness controls.
Do you provide motor pre-match support for right-angle units?
Yes. We review motor specs and recommend interface and ratio combinations before sample build.
